Evaluating and Debugging AI Agents

Trajectory-level scoring, tool-call accuracy, LangSmith traces, agent benchmarks, and failure root-cause analysis

Published

July 30, 2025

Keywords: agent evaluation, trajectory scoring, tool-call accuracy, LangSmith, agent benchmarks, AgentBench, GAIA, tau-bench, SWE-bench, LLM-as-judge, failure analysis, agent debugging, agent observability, agent tracing, pass@k, step-level evaluation

Introduction

You can build a ReAct agent in an afternoon. Getting it to work reliably on Monday, Wednesday, and Friday — with different queries, different retrieved documents, and different model versions — is a different problem entirely.

Evaluating AI agents is fundamentally harder than evaluating LLMs. A chat model takes a prompt and returns text; you compare the text to a reference. An agent takes a goal and produces a trajectory — a sequence of thoughts, tool calls, observations, and decisions — before arriving at a final answer. Two trajectories can reach the same correct answer through entirely different paths, or reach a wrong answer despite every individual step looking reasonable.

The GAIA benchmark showed that human respondents solved 92% of questions while GPT-4 with plugins solved only 15%. AgentBench found a “significant disparity” between commercial and open-source models across 8 interactive environments. τ-bench revealed that even GPT-4o succeeds on fewer than 50% of tool-agent-user interaction tasks — and drops below 25% when consistency across multiple trials is measured.

This article covers the full evaluation and debugging stack for retrieval agents: what to measure (final-answer correctness, trajectory quality, tool-call accuracy), how to measure it (LLM-as-judge, programmatic scorers, benchmarks), how to trace failures (LangSmith, structured logging), and how to systematically debug when things go wrong.

Why Agent Evaluation Is Hard

The Non-Determinism Problem

Agents are non-deterministic by nature. Even with temperature=0, the same query can produce different trajectories depending on:

  • Retrieval results that change as the underlying corpus is updated
  • Tool outputs that vary with time (web search, API calls, database contents)
  • Model updates that shift behavior between versions
  • Context window packing — identical messages in different order can alter responses

This means a single test run proves very little. You need statistical evaluation: run the same query multiple times and measure consistency.

The Evaluation Dimensions

graph TB
    AE["Agent Evaluation"] --> FA["Final Answer<br/>Correctness"]
    AE --> TQ["Trajectory<br/>Quality"]
    AE --> TC["Tool-Call<br/>Accuracy"]
    AE --> EF["Efficiency"]
    AE --> SF["Safety &<br/>Guardrails"]

    FA --> FA1["Exact match"]
    FA --> FA2["Semantic similarity"]
    FA --> FA3["LLM-as-judge"]

    TQ --> TQ1["Step correctness"]
    TQ --> TQ2["Reasoning quality"]
    TQ --> TQ3["Recovery from errors"]

    TC --> TC1["Correct tool selected"]
    TC --> TC2["Correct arguments"]
    TC --> TC3["No unnecessary calls"]

    EF --> EF1["Steps to completion"]
    EF --> EF2["Token usage"]
    EF --> EF3["Latency"]

    SF --> SF1["Stays in scope"]
    SF --> SF2["No data leakage"]
    SF --> SF3["Respects permissions"]

    style AE fill:#3498db,color:#fff
    style FA fill:#2ecc71,color:#fff
    style TQ fill:#9b59b6,color:#fff
    style TC fill:#e67e22,color:#fff
    style EF fill:#f39c12,color:#000
    style SF fill:#e74c3c,color:#fff

Dimension What It Measures Why It Matters
Final answer correctness Is the output right? The bottom line — users care about the answer
Trajectory quality Did the agent reason well? A correct answer via bad reasoning is fragile
Tool-call accuracy Did it call the right tools with the right args? Wrong tools waste time and money
Efficiency Steps, tokens, latency Cost and user experience
Safety & guardrails Did it stay within bounds? Prevents data leaks and unauthorized actions

Final Answer Evaluation

Exact Match and Fuzzy Match

The simplest evaluator: does the agent’s answer match the expected answer?

from difflib import SequenceMatcher


def exact_match(predicted: str, expected: str) -> bool:
    """Case-insensitive exact match after normalization."""
    return predicted.strip().lower() == expected.strip().lower()


def fuzzy_match(predicted: str, expected: str, threshold: float = 0.85) -> bool:
    """Fuzzy string match using sequence similarity."""
    ratio = SequenceMatcher(
        None, predicted.strip().lower(), expected.strip().lower()
    ).ratio()
    return ratio >= threshold

Exact match works for factual questions with short answers (“Paris”, “42”, “2024-03-15”). It fails for open-ended answers where multiple phrasings are correct.

Semantic Similarity

Compare embeddings of the predicted and expected answers:

from openai import OpenAI
import numpy as np

client = OpenAI()


def embed(text: str) -> list[float]:
    response = client.embeddings.create(
        model="text-embedding-3-small", input=text
    )
    return response.data[0].embedding


def semantic_similarity(predicted: str, expected: str) -> float:
    """Cosine similarity between embeddings of predicted and expected."""
    v1 = np.array(embed(predicted))
    v2 = np.array(embed(expected))
    return float(np.dot(v1, v2) / (np.linalg.norm(v1) * np.linalg.norm(v2)))

LLM-as-Judge

For complex answers, use a strong LLM to judge correctness. Zheng et al. (2023) showed that GPT-4 judges achieve over 80% agreement with human evaluators — the same agreement level as between humans themselves.

def llm_judge_answer(
    question: str,
    predicted: str,
    expected: str,
    model: str = "gpt-4o",
) -> dict:
    """Use an LLM to judge whether the predicted answer is correct."""
    prompt = f"""You are an expert evaluator. Judge whether the predicted answer
correctly addresses the question compared to the expected answer.

Question: {question}

Expected Answer: {expected}

Predicted Answer: {predicted}

Evaluate on these criteria:
1. **Correctness**: Does the prediction contain the key facts from the expected answer?
2. **Completeness**: Does it cover all important points?
3. **Hallucination**: Does it include any false claims not in the expected answer?

Respond with a JSON object:
{{
    "correctness": <0.0-1.0>,
    "completeness": <0.0-1.0>,
    "hallucination": <0.0-1.0 where 0 means no hallucination>,
    "overall_score": <0.0-1.0>,
    "reasoning": "<brief explanation>"
}}"""

    response = client.chat.completions.create(
        model=model,
        messages=[{"role": "user", "content": prompt}],
        temperature=0,
        response_format={"type": "json_object"},
    )
    import json
    return json.loads(response.choices[0].message.content)

Evaluator Comparison

Evaluator Latency Cost Handles Open-Ended Handles Partial Correctness
Exact match ~0ms Free No No
Fuzzy match ~0ms Free Slightly No
Semantic similarity ~100ms ~$0.0001 Yes No (single score)
LLM-as-judge ~2s ~$0.01 Yes Yes (multi-criteria)

Recommendation: Use exact match for factual benchmarks, LLM-as-judge for quality evaluation, and semantic similarity as a fast pre-filter.

Trajectory-Level Scoring

Final answer correctness tells you what the agent got right or wrong, but not why. Trajectory-level evaluation scores the process — the sequence of thoughts and tool calls — not just the outcome.

Why Trajectory Matters

Two agents can both answer “Paris has a population of 2.1 million”:

  • Agent A: Thought → search("capital of France") → Observation: “Paris” → Thought → search("population of Paris") → Observation: “2.1M” → Answer
  • Agent B: Thought → search("population Paris France capital city urban area metro") → Observation: (irrelevant results) → Thought → search("Paris population") → Observation: “2.1M” → Thought → search("is Paris the capital of France") → Observation: “Yes” → Answer

Both are correct. Agent A is clearly better: fewer steps, more targeted queries, logical decomposition. Trajectory scoring captures this difference.

Step-Level Grading

Grade each step independently, then aggregate:

from dataclasses import dataclass


@dataclass
class TrajectoryStep:
    """A single step in an agent trajectory."""
    step_type: str          # "thought", "tool_call", "observation", "answer"
    content: str
    tool_name: str | None = None
    tool_args: dict | None = None
    tool_result: str | None = None


@dataclass
class StepScore:
    relevance: float        # Was this step relevant to the goal?
    correctness: float      # Was the reasoning/action correct?
    efficiency: float       # Was this step necessary?
    explanation: str


def score_trajectory_step(
    step: TrajectoryStep,
    goal: str,
    previous_steps: list[TrajectoryStep],
    model: str = "gpt-4o",
) -> StepScore:
    """Score an individual trajectory step using an LLM judge."""
    history = "\n".join(
        f"  [{s.step_type}] {s.content[:200]}" for s in previous_steps[-5:]
    )

    prompt = f"""Evaluate this agent step in the context of the goal and history.

Goal: {goal}

Recent History:
{history}

Current Step:
  Type: {step.step_type}
  Content: {step.content[:500]}
  Tool: {step.tool_name or 'N/A'}
  Args: {step.tool_args or 'N/A'}

Score each dimension from 0.0 to 1.0:
- relevance: Is this step relevant to achieving the goal?
- correctness: Is the reasoning or tool call logically correct?
- efficiency: Is this step necessary, or could it be skipped?

Respond as JSON: {{"relevance": ..., "correctness": ..., "efficiency": ..., "explanation": "..."}}"""

    response = client.chat.completions.create(
        model=model,
        messages=[{"role": "user", "content": prompt}],
        temperature=0,
        response_format={"type": "json_object"},
    )
    import json
    data = json.loads(response.choices[0].message.content)
    return StepScore(**data)

Trajectory-Level Aggregate Score

Combine step scores into an overall trajectory quality metric:

def score_trajectory(
    steps: list[TrajectoryStep],
    goal: str,
    expected_answer: str,
    actual_answer: str,
) -> dict:
    """Score an entire agent trajectory."""
    # Score each step
    step_scores = []
    for i, step in enumerate(steps):
        score = score_trajectory_step(step, goal, steps[:i])
        step_scores.append(score)

    # Aggregate
    n = len(step_scores)
    avg_relevance = sum(s.relevance for s in step_scores) / n if n else 0
    avg_correctness = sum(s.correctness for s in step_scores) / n if n else 0
    avg_efficiency = sum(s.efficiency for s in step_scores) / n if n else 0

    # Final answer score
    answer_score = llm_judge_answer(goal, actual_answer, expected_answer)

    return {
        "answer_correctness": answer_score["overall_score"],
        "trajectory_relevance": avg_relevance,
        "trajectory_correctness": avg_correctness,
        "trajectory_efficiency": avg_efficiency,
        "num_steps": n,
        "step_scores": step_scores,
        "overall": (
            0.4 * answer_score["overall_score"]
            + 0.2 * avg_relevance
            + 0.2 * avg_correctness
            + 0.2 * avg_efficiency
        ),
    }

graph LR
    subgraph Trajectory["Agent Trajectory"]
        S1["Step 1<br/>Thought"] --> S2["Step 2<br/>Tool Call"]
        S2 --> S3["Step 3<br/>Observation"]
        S3 --> S4["Step 4<br/>Thought"]
        S4 --> S5["Step 5<br/>Answer"]
    end

    subgraph Scoring["Step-Level Scoring"]
        S1 --> SC1["Relevance: 0.9<br/>Correctness: 1.0<br/>Efficiency: 0.8"]
        S2 --> SC2["Relevance: 1.0<br/>Correctness: 1.0<br/>Efficiency: 1.0"]
        S4 --> SC4["Relevance: 0.9<br/>Correctness: 0.9<br/>Efficiency: 0.7"]
    end

    SC1 --> AGG["Aggregate<br/>Score: 0.87"]
    SC2 --> AGG
    SC4 --> AGG

    style AGG fill:#2ecc71,color:#fff

Tool-Call Accuracy

For retrieval agents, the tools are the interface to knowledge. Getting tool calls wrong means getting answers wrong. Tool-call accuracy decomposes into three questions:

  1. Did the agent select the right tool? (tool selection accuracy)
  2. Did it pass the right arguments? (argument accuracy)
  3. Did it avoid unnecessary calls? (call efficiency)

Measuring Tool-Call Accuracy

from dataclasses import dataclass


@dataclass
class ExpectedToolCall:
    """A tool call that the ideal trajectory should include."""
    tool_name: str
    required_args: dict  # Minimum expected arguments
    optional: bool = False  # If True, this call is nice-to-have


@dataclass
class ToolCallEvaluation:
    tool_selection_accuracy: float   # % of expected tools that were called
    argument_accuracy: float         # % of args that matched expected values
    precision: float                 # % of actual calls that were expected
    recall: float                    # % of expected calls that were made
    unnecessary_calls: int           # Calls not matching any expected call


def evaluate_tool_calls(
    actual_calls: list[dict],
    expected_calls: list[ExpectedToolCall],
) -> ToolCallEvaluation:
    """Evaluate tool call accuracy against expected behavior."""
    matched_expected = set()
    matched_actual = set()
    total_arg_score = 0.0
    arg_evaluations = 0

    for i, expected in enumerate(expected_calls):
        if expected.optional:
            continue
        for j, actual in enumerate(actual_calls):
            if actual["name"] == expected.tool_name and j not in matched_actual:
                matched_expected.add(i)
                matched_actual.add(j)

                # Score argument accuracy
                actual_args = actual.get("arguments", {})
                if expected.required_args:
                    matches = sum(
                        1 for k, v in expected.required_args.items()
                        if k in actual_args and _args_match(actual_args[k], v)
                    )
                    total_arg_score += matches / len(expected.required_args)
                    arg_evaluations += 1
                break

    required_count = sum(1 for e in expected_calls if not e.optional)
    recall = len(matched_expected) / required_count if required_count else 1.0
    precision = len(matched_actual) / len(actual_calls) if actual_calls else 1.0
    arg_acc = total_arg_score / arg_evaluations if arg_evaluations else 1.0
    unnecessary = len(actual_calls) - len(matched_actual)

    return ToolCallEvaluation(
        tool_selection_accuracy=recall,
        argument_accuracy=arg_acc,
        precision=precision,
        recall=recall,
        unnecessary_calls=unnecessary,
    )


def _args_match(actual, expected) -> bool:
    """Flexible argument matching — handles type coercion and substring match."""
    if isinstance(expected, str) and isinstance(actual, str):
        return expected.lower() in actual.lower()
    return str(actual) == str(expected)

Example: Evaluating a Retrieval Agent

# What the agent actually did
actual_calls = [
    {"name": "vector_search", "arguments": {"query": "revenue 2024", "top_k": 5}},
    {"name": "vector_search", "arguments": {"query": "annual report financials", "top_k": 5}},
    {"name": "web_search", "arguments": {"query": "company revenue 2024"}},
]

# What we expected
expected = [
    ExpectedToolCall("vector_search", {"query": "revenue 2024"}),
    ExpectedToolCall("web_search", {"query": "revenue 2024"}, optional=True),
]

result = evaluate_tool_calls(actual_calls, expected)
print(f"Selection accuracy: {result.tool_selection_accuracy:.0%}")
print(f"Argument accuracy:  {result.argument_accuracy:.0%}")
print(f"Precision:          {result.precision:.0%}")
print(f"Unnecessary calls:  {result.unnecessary_calls}")
Selection accuracy: 100%
Argument accuracy:  100%
Precision:          33%
Unnecessary calls:  2

The agent found the right answer but made two unnecessary calls — a common pattern worth tracking.

Agent Benchmarks

Standardized benchmarks let you compare agents across models, architectures, and configurations. Here are the key benchmarks for retrieval and tool-using agents:

Benchmark Landscape

Benchmark Focus Tasks Key Metric Scale
GAIA General assistant abilities 466 real-world questions Accuracy (human: 92%, GPT-4: 15%) 3 difficulty levels
AgentBench LLM-as-agent across environments 8 environments (OS, DB, web, games) Overall score, per-env accuracy ICLR 2024
τ-bench Tool-agent-user interaction Retail + airline domains pass@k (reliability over k trials) Domain-specific policies
SWE-bench Real-world software engineering 2,294 GitHub issues % resolved Requires code edits
HotpotQA Multi-hop question answering 113k QA pairs F1, exact match Wikipedia-based
WebArena Web browsing autonomy 812 web tasks Task success rate Real web environments

The pass@k Metric

τ-bench introduced pass@k — the probability that an agent succeeds on all k independent trials of the same task. This measures reliability, not just capability:

\text{pass}^k = \prod_{i=1}^{k} P(\text{success on trial } i)

If an agent succeeds 70% of the time on a single trial, its pass@8 reliability is:

\text{pass}^8 = 0.7^8 \approx 0.057 = 5.7\%

This is why τ-bench found GPT-4o achieving pass@8 below 25% in retail tasks — even high single-trial accuracy collapses under repeated independent runs.

def compute_pass_at_k(trial_results: list[bool], k: int) -> float:
    """Compute pass@k: probability of success on all k trials.

    Uses empirical estimation from multiple trial groups.
    """
    n = len(trial_results)
    if n < k:
        raise ValueError(f"Need at least {k} trials, got {n}")

    # Count successes
    successes = sum(trial_results)
    single_pass_rate = successes / n

    # pass@k = (single_pass_rate)^k (assumes independence)
    return single_pass_rate ** k


# Example: 7 successes out of 10 trials
trials = [True, True, False, True, True, True, False, True, True, False]
print(f"pass@1: {compute_pass_at_k(trials, 1):.1%}")
print(f"pass@4: {compute_pass_at_k(trials, 4):.1%}")
print(f"pass@8: {compute_pass_at_k(trials, 8):.1%}")
pass@1: 70.0%
pass@4: 24.0%
pass@8:  5.8%

Running a Custom Benchmark Suite

Build a task set tailored to your retrieval agent’s domain:

import json
from dataclasses import dataclass, field


@dataclass
class BenchmarkTask:
    """A single evaluation task for a retrieval agent."""
    task_id: str
    query: str
    expected_answer: str
    expected_tool_calls: list[ExpectedToolCall] = field(default_factory=list)
    difficulty: str = "medium"  # easy, medium, hard
    category: str = "general"


@dataclass
class BenchmarkResult:
    task_id: str
    answer_correct: bool
    answer_score: float
    trajectory_score: float
    tool_accuracy: float
    num_steps: int
    latency_seconds: float
    total_tokens: int
    error: str | None = None


def run_benchmark(
    agent,
    tasks: list[BenchmarkTask],
    num_trials: int = 3,
) -> dict:
    """Run a benchmark suite with multiple trials per task."""
    all_results: dict[str, list[BenchmarkResult]] = {}

    for task in tasks:
        task_results = []
        for trial in range(num_trials):
            result = evaluate_single_task(agent, task)
            task_results.append(result)
        all_results[task.task_id] = task_results

    # Compute aggregate metrics
    summary = compute_benchmark_summary(all_results, tasks)
    return summary


def compute_benchmark_summary(
    results: dict[str, list[BenchmarkResult]],
    tasks: list[BenchmarkTask],
) -> dict:
    """Aggregate benchmark results into a summary report."""
    task_pass_rates = {}
    for task_id, trials in results.items():
        successes = sum(1 for t in trials if t.answer_correct)
        task_pass_rates[task_id] = successes / len(trials)

    overall_pass1 = sum(task_pass_rates.values()) / len(task_pass_rates)

    # Group by difficulty
    difficulty_scores = {}
    task_lookup = {t.task_id: t for t in tasks}
    for task_id, rate in task_pass_rates.items():
        diff = task_lookup[task_id].difficulty
        difficulty_scores.setdefault(diff, []).append(rate)

    return {
        "overall_pass@1": overall_pass1,
        "by_difficulty": {
            d: sum(rates) / len(rates)
            for d, rates in difficulty_scores.items()
        },
        "per_task": task_pass_rates,
        "total_tasks": len(tasks),
    }

Tracing with LangSmith

LangSmith is a framework-agnostic platform for tracing, debugging, and evaluating AI agents. It captures the complete run tree — every LLM call, tool invocation, retrieval step, and intermediate result — as a hierarchical trace.

Setting Up Tracing

import os

# Set environment variables to enable LangSmith tracing
os.environ["LANGCHAIN_TRACING_V2"] = "true"
os.environ["LANGCHAIN_API_KEY"] = "your-langsmith-api-key"
os.environ["LANGCHAIN_PROJECT"] = "retrieval-agent-eval"

With these set, every LangChain/LangGraph call is automatically traced. For non-LangChain code, use the @traceable decorator:

from langsmith import traceable


@traceable(name="retrieval_agent_step")
def agent_step(query: str, context: list[str]) -> str:
    """A single agent step that gets traced in LangSmith."""
    # Your agent logic here
    response = client.chat.completions.create(
        model="gpt-4o",
        messages=[
            {"role": "system", "content": "You are a retrieval agent."},
            {"role": "user", "content": f"Context: {context}\n\nQuery: {query}"},
        ],
    )
    return response.choices[0].message.content


@traceable(name="tool_execution")
def execute_search(query: str, top_k: int = 5) -> list[dict]:
    """Search execution that gets its own trace span."""
    # Your search logic here
    results = vector_store.similarity_search(query, k=top_k)
    return [{"text": r.page_content, "score": r.metadata.get("score")} for r in results]

The Run Tree

LangSmith organizes traces as a run tree — a hierarchy of parent and child runs that mirrors the agent’s execution flow:

graph TB
    R["Agent Run<br/>query: 'Compare Q3 revenue'<br/>⏱ 8.2s | $0.04"]
    R --> L1["LLM Call<br/>model: gpt-4o<br/>tokens: 1,240"]
    R --> T1["Tool: vector_search<br/>query: 'Q3 revenue 2024'<br/>⏱ 0.3s"]
    R --> L2["LLM Call<br/>model: gpt-4o<br/>tokens: 2,100"]
    R --> T2["Tool: vector_search<br/>query: 'Q3 revenue 2023'<br/>⏱ 0.2s"]
    R --> L3["LLM Call<br/>model: gpt-4o<br/>tokens: 1,800"]

    T1 --> T1R["Retrieved 5 chunks<br/>relevance: [0.92, 0.88, ...]"]
    T2 --> T2R["Retrieved 5 chunks<br/>relevance: [0.91, 0.85, ...]"]

    style R fill:#3498db,color:#fff
    style L1 fill:#9b59b6,color:#fff
    style L2 fill:#9b59b6,color:#fff
    style L3 fill:#9b59b6,color:#fff
    style T1 fill:#e67e22,color:#fff
    style T2 fill:#e67e22,color:#fff

Each node in the tree captures:

  • Inputs and outputs of every LLM call and tool invocation
  • Latency for each step
  • Token counts and estimated cost
  • Metadata (model name, temperature, tool arguments)
  • Errors with full stack traces

Evaluation Datasets in LangSmith

Create a dataset of (input, expected output) pairs and run automated evaluations:

from langsmith import Client

ls_client = Client()

# Create a dataset
dataset = ls_client.create_dataset(
    "retrieval-agent-eval-v1",
    description="Evaluation tasks for the Q&A retrieval agent",
)

# Add examples
examples = [
    {
        "inputs": {"query": "What was our Q3 2024 revenue?"},
        "outputs": {"answer": "Q3 2024 revenue was $12.4M, up 18% YoY."},
    },
    {
        "inputs": {"query": "Summarize the main findings from the safety audit."},
        "outputs": {
            "answer": "The audit found 3 critical and 7 minor issues..."
        },
    },
]

for ex in examples:
    ls_client.create_example(
        inputs=ex["inputs"],
        outputs=ex["outputs"],
        dataset_id=dataset.id,
    )

Running Evaluations

from langsmith.evaluation import evaluate


def predict(inputs: dict) -> dict:
    """Run the agent and return its answer."""
    result = agent.invoke({"messages": [{"role": "user", "content": inputs["query"]}]})
    return {"answer": result["messages"][-1].content}


def correctness_evaluator(run, example) -> dict:
    """Custom evaluator that uses LLM-as-judge."""
    predicted = run.outputs["answer"]
    expected = example.outputs["answer"]
    question = example.inputs["query"]
    score = llm_judge_answer(question, predicted, expected)
    return {"key": "correctness", "score": score["overall_score"]}


# Run the evaluation
results = evaluate(
    predict,
    data="retrieval-agent-eval-v1",
    evaluators=[correctness_evaluator],
    experiment_prefix="agent-v2.1",
)

Failure Root-Cause Analysis

When an agent fails, the question is not just “what went wrong?” but “where in the trajectory did it go wrong, and why?” Systematic failure analysis turns individual debugging sessions into lasting improvements.

Failure Taxonomy

graph TB
    F["Agent Failure"] --> P["Planning<br/>Failures"]
    F --> T["Tool<br/>Failures"]
    F --> R["Reasoning<br/>Failures"]
    F --> E["Execution<br/>Failures"]

    P --> P1["Wrong decomposition<br/>of the query"]
    P --> P2["Missed sub-question"]
    P --> P3["Wrong ordering<br/>of steps"]

    T --> T1["Selected wrong tool"]
    T --> T2["Wrong arguments"]
    T --> T3["Ignored tool output"]
    T --> T4["Excessive tool calls"]

    R --> R1["Hallucinated facts"]
    R --> R2["Contradicted evidence"]
    R --> R3["Premature conclusion"]
    R --> R4["Lost context"]

    E --> E1["Tool timeout"]
    E --> E2["Rate limit hit"]
    E --> E3["Context overflow"]
    E --> E4["Parsing error"]

    style F fill:#e74c3c,color:#fff
    style P fill:#f39c12,color:#000
    style T fill:#e67e22,color:#fff
    style R fill:#9b59b6,color:#fff
    style E fill:#95a5a6,color:#fff

Failure Category Example Root Cause Fix
Wrong tool Agent uses web_search instead of vector_search for internal docs Ambiguous tool descriptions Improve tool descriptions, add routing hints
Wrong arguments vector_search(query="?") with vague query LLM failed to extract key terms Add few-shot examples to system prompt
Hallucination Agent invents a statistic not in any retrieved chunk Retrieved chunks didn’t contain the answer Add “only cite retrieved information” instruction
Premature answer Agent answers after 1 tool call when 3 are needed Insufficient reasoning depth Add “verify all sub-questions are answered” check
Infinite loop Agent retries the same failing search 5 times No loop detection Add stopping conditions and deduplication
Context overflow Long conversation exceeds context window Too many retrieved chunks accumulated Summarize earlier context, limit chunk count

Automated Failure Classification

Instead of manually reading traces, classify failures programmatically:

@dataclass
class FailureAnalysis:
    category: str        # planning, tool, reasoning, execution
    subcategory: str     # specific failure type
    step_index: int      # where in the trajectory it failed
    severity: str        # critical, major, minor
    explanation: str
    suggested_fix: str


def analyze_failure(
    query: str,
    trajectory: list[TrajectoryStep],
    expected_answer: str,
    actual_answer: str,
    model: str = "gpt-4o",
) -> FailureAnalysis:
    """Use an LLM to perform root-cause analysis on a failed trajectory."""
    traj_str = "\n".join(
        f"Step {i+1} [{s.step_type}]: {s.content[:200]}"
        for i, s in enumerate(trajectory)
    )

    prompt = f"""Analyze why this agent trajectory produced a wrong answer.

Query: {query}
Expected Answer: {expected_answer}
Actual Answer: {actual_answer}

Trajectory:
{traj_str}

Classify the root cause:
- category: one of [planning, tool, reasoning, execution]
- subcategory: specific failure (e.g., "wrong_tool", "hallucination", "premature_answer")
- step_index: which step (1-indexed) first went wrong
- severity: critical, major, or minor
- explanation: what happened and why
- suggested_fix: concrete improvement to prevent this failure

Respond as JSON."""

    response = client.chat.completions.create(
        model=model,
        messages=[{"role": "user", "content": prompt}],
        temperature=0,
        response_format={"type": "json_object"},
    )
    import json
    data = json.loads(response.choices[0].message.content)
    return FailureAnalysis(**data)

Building a Failure Dashboard

Aggregate failure analyses across your evaluation runs to identify systematic issues:

from collections import Counter


def failure_report(analyses: list[FailureAnalysis]) -> dict:
    """Aggregate failure analyses into a report."""
    category_counts = Counter(a.category for a in analyses)
    subcategory_counts = Counter(a.subcategory for a in analyses)
    severity_counts = Counter(a.severity for a in analyses)
    avg_step = sum(a.step_index for a in analyses) / len(analyses) if analyses else 0

    # Most common fixes
    fix_counts = Counter(a.suggested_fix for a in analyses)

    return {
        "total_failures": len(analyses),
        "by_category": dict(category_counts.most_common()),
        "by_subcategory": dict(subcategory_counts.most_common(10)),
        "by_severity": dict(severity_counts),
        "avg_failure_step": round(avg_step, 1),
        "top_suggested_fixes": fix_counts.most_common(5),
    }

A Complete Evaluation Pipeline

Here is how all the pieces fit together in a production evaluation workflow:

graph TB
    subgraph Define["1. Define"]
        D1["Evaluation Dataset<br/>(queries + expected answers)"]
        D2["Expected Tool Calls"]
        D3["Quality Criteria"]
    end

    subgraph Run["2. Run"]
        R1["Execute Agent<br/>(multiple trials per task)"]
        R2["Capture Traces<br/>(LangSmith)"]
        R3["Record Trajectories"]
    end

    subgraph Score["3. Score"]
        S1["Final Answer<br/>(LLM-as-judge)"]
        S2["Trajectory Quality<br/>(step-level scoring)"]
        S3["Tool-Call Accuracy<br/>(precision + recall)"]
        S4["Efficiency<br/>(steps, tokens, latency)"]
    end

    subgraph Analyze["4. Analyze"]
        A1["Failure Classification"]
        A2["Regression Detection"]
        A3["Improvement Priorities"]
    end

    Define --> Run --> Score --> Analyze

    style Define fill:#3498db,color:#fff
    style Run fill:#2ecc71,color:#fff
    style Score fill:#9b59b6,color:#fff
    style Analyze fill:#e74c3c,color:#fff


class AgentEvaluationPipeline:
    """End-to-end evaluation pipeline for retrieval agents."""

    def __init__(self, agent, evaluator_model: str = "gpt-4o"):
        self.agent = agent
        self.evaluator_model = evaluator_model

    def run_evaluation(
        self,
        tasks: list[BenchmarkTask],
        num_trials: int = 3,
    ) -> dict:
        """Run the full evaluation pipeline."""
        results = []

        for task in tasks:
            for trial in range(num_trials):
                # Run agent and capture trajectory
                trajectory, answer, metadata = self._run_and_capture(task)

                # Score final answer
                answer_eval = llm_judge_answer(
                    task.query, answer, task.expected_answer,
                    model=self.evaluator_model,
                )

                # Score trajectory
                traj_eval = score_trajectory(
                    trajectory, task.query,
                    task.expected_answer, answer,
                )

                # Score tool calls
                actual_calls = [
                    {"name": s.tool_name, "arguments": s.tool_args}
                    for s in trajectory if s.step_type == "tool_call"
                ]
                tool_eval = evaluate_tool_calls(
                    actual_calls, task.expected_tool_calls,
                )

                # Failure analysis (if answer is wrong)
                failure = None
                if answer_eval["overall_score"] < 0.5:
                    failure = analyze_failure(
                        task.query, trajectory,
                        task.expected_answer, answer,
                    )

                results.append({
                    "task_id": task.task_id,
                    "trial": trial,
                    "answer_score": answer_eval["overall_score"],
                    "trajectory_score": traj_eval["overall"],
                    "tool_precision": tool_eval.precision,
                    "tool_recall": tool_eval.recall,
                    "num_steps": len(trajectory),
                    "tokens": metadata.get("total_tokens", 0),
                    "latency": metadata.get("latency_seconds", 0),
                    "failure": failure,
                })

        return self._aggregate(results)

    def _run_and_capture(self, task):
        """Run agent and capture trajectory + metadata."""
        import time
        start = time.time()
        # ... run agent, capture steps ...
        elapsed = time.time() - start
        # Return (trajectory, final_answer, metadata)
        return trajectory, answer, {"latency_seconds": elapsed}

    def _aggregate(self, results: list[dict]) -> dict:
        """Compute aggregate metrics."""
        n = len(results)
        return {
            "num_evaluations": n,
            "avg_answer_score": sum(r["answer_score"] for r in results) / n,
            "avg_trajectory_score": sum(r["trajectory_score"] for r in results) / n,
            "avg_tool_precision": sum(r["tool_precision"] for r in results) / n,
            "avg_tool_recall": sum(r["tool_recall"] for r in results) / n,
            "avg_steps": sum(r["num_steps"] for r in results) / n,
            "avg_latency": sum(r["latency"] for r in results) / n,
            "failure_rate": sum(1 for r in results if r["failure"]) / n,
            "failures": [r["failure"] for r in results if r["failure"]],
        }

Debugging Playbook

When evaluation reveals a problem, use this systematic approach:

Step 1: Reproduce with Tracing

# Enable verbose tracing and re-run the failing query
os.environ["LANGCHAIN_TRACING_V2"] = "true"

result = agent.invoke(
    {"messages": [{"role": "user", "content": failing_query}]},
    config={"configurable": {"thread_id": "debug-session-001"}},
)

Step 2: Identify the Divergence Point

Compare the successful trajectory (from your evaluation dataset) with the failing one:

def find_divergence(
    expected_steps: list[str],
    actual_steps: list[TrajectoryStep],
) -> int:
    """Find the first step where the trajectory diverges from expected."""
    for i, (expected, actual) in enumerate(zip(expected_steps, actual_steps)):
        if actual.tool_name and actual.tool_name not in expected:
            return i
        if actual.step_type == "answer" and i < len(expected_steps) - 1:
            return i  # Answered too early
    return len(actual_steps)  # Diverged at the end (incomplete)

Step 3: Apply Targeted Fixes

Root Cause Fix Where to Apply
Wrong tool selection Improve tool descriptions, add negative examples System prompt / tool schemas
Bad arguments Add few-shot examples of correct tool calls System prompt
Hallucination Add “only use information from tool results” System prompt
Premature stop Add “check all sub-questions before answering” System prompt / stopping logic
Infinite loop Add stopping conditions and budget limits Agent loop
Context overflow Limit retrieved chunks, summarize history Retrieval config / memory system
Inconsistent behavior Lower temperature, add structured output LLM config

Step 4: Regression Test

After applying a fix, re-run the full benchmark to verify:

  1. The failing task now passes
  2. No previously passing tasks regress
  3. Overall metrics improve or hold steady
# Before fix
baseline = pipeline.run_evaluation(tasks, num_trials=3)

# Apply fix...

# After fix
updated = pipeline.run_evaluation(tasks, num_trials=3)

# Compare
print(f"Answer score: {baseline['avg_answer_score']:.2f} → {updated['avg_answer_score']:.2f}")
print(f"Failure rate: {baseline['failure_rate']:.1%} → {updated['failure_rate']:.1%}")

# Check for regressions
for task_id in baseline["per_task"]:
    old = baseline["per_task"][task_id]
    new = updated["per_task"].get(task_id, 0)
    if new < old - 0.1:
        print(f"⚠ REGRESSION on {task_id}: {old:.2f} → {new:.2f}")

Conclusion

Agent evaluation requires thinking at three levels simultaneously: the answer (is it correct?), the trajectory (did the agent reason well?), and the tooling (did it use tools correctly?). Standard LLM evaluation techniques — metrics on final text output — miss two-thirds of the picture.

Key takeaways:

  • Measure trajectory, not just outcome. A correct answer from a sloppy trajectory is fragile. Step-level scoring with LLM-as-judge reveals reasoning quality.
  • Tool-call accuracy is its own dimension. For retrieval agents, tool precision and recall directly predict answer quality. Track selection accuracy, argument correctness, and unnecessary calls separately.
  • Single trials are misleading. Use pass@k to measure reliability. An agent that succeeds 70% of the time has only 5.7% reliability over 8 trials.
  • Trace everything. LangSmith (or equivalent) captures the full run tree — LLM calls, tool invocations, retrieved chunks, latencies. This is your primary debugging tool.
  • Classify failures systematically. Automated root-cause analysis with LLM-as-judge turns ad-hoc debugging into a data-driven improvement process. Track failure categories over time to prioritize fixes.
  • Regression test every change. Agent behavior is sensitive to prompt changes, model updates, and retrieval config. A fix for one query can break ten others.

Build your evaluation pipeline early — before the agent reaches production — and run it continuously. The cost of evaluation is a fraction of the cost of undetected failures in production.

References

  1. X. Liu et al., “AgentBench: Evaluating LLMs as Agents,” ICLR 2024, arXiv:2308.03688. Available: https://arxiv.org/abs/2308.03688
  2. G. Mialon, C. Fourrier, C. Swift, T. Wolf, Y. LeCun, and T. Scialom, “GAIA: A Benchmark for General AI Assistants,” arXiv:2311.12983, 2023. Available: https://arxiv.org/abs/2311.12983
  3. S. Yao, N. Shinn, P. Razavi, and K. Narasimhan, “τ-bench: A Benchmark for Tool-Agent-User Interaction in Real-World Domains,” arXiv:2406.12045, 2024. Available: https://arxiv.org/abs/2406.12045
  4. C. E. Jimenez et al., “SWE-bench: Can Language Models Resolve Real-World GitHub Issues?” ICLR 2024, arXiv:2310.06770. Available: https://arxiv.org/abs/2310.06770
  5. L. Zheng et al., “Judging LLM-as-a-Judge with MT-Bench and Chatbot Arena,” NeurIPS 2023 Datasets and Benchmarks, arXiv:2306.05685. Available: https://arxiv.org/abs/2306.05685
  6. LangChain, “LangSmith Documentation,” docs.langchain.com, 2024. Available: https://docs.langchain.com/langsmith
  7. S. Yao et al., “ReAct: Synergizing Reasoning and Acting in Language Models,” ICLR 2023, arXiv:2210.03629. Available: https://arxiv.org/abs/2210.03629

Read More
